| AC Current (max) |
2000 A; accuracy: ±(2.5% + 5 digits) |
| DC Current |
— (DC current measurement available in UT221/UT222, not UT220) |
| AC Voltage |
Up to 750 V; accuracy: ±(1.2% + 5 digits) |
| DC Voltage |
Up to 1000 V; accuracy: ±(0.8% + 1 digit) |
| Resistance |
Up to 20 MΩ; accuracy: ±(1.0% + 2 digits) |
| Capacitance |
Up to 60 mF; accuracy: ±(3.0% + 5 digits) |
| Frequency |
Up to 20 MHz; accuracy: ±(0.1% + 3 digits) |
| Temperature Range |
–40 °C to 1000 °C (–40 °F to 1832 °F); accuracy: ±(1% + 10 °C) |
| Display Resolution |
2000 counts |
| Jaw Opening Diameter |
63 mm |
| Auto‑range |
Yes |
| Functions Supported |
Diode test, continuity buzzer, data-hold, MAX/MIN recording, low battery indicator |
| True RMS |
No (only available in UT221/UT222) |
| Duty-Cycle Measurement |
No (UT220 only measures basic AC current) |
| Other Features |
Analog bar graph; full icon display; input impedance ≥ 10 MΩ |
| Power Supply |
9 V battery (6F22) |
| Display Size |
43 × 30 mm LCD |
| Weight (net) |
389 g |
| Dimensions (L × W × H) |
298 × 107 × 47 mm |
| Safety & Certifications |
CE, UKCA, cETLus; CAT III 1000 V / CAT IV 600 V protection (depending on region) |
| Includes Accessories |
Test leads; gift box; carrying bag; English manual |
