| Display |
6000-count LCD, backlit |
| Range Selection |
Auto-ranging |
| DC Voltage |
600 mV / 6 V / 60 V / 600 V; ±(0.5% + 3 digits) |
| AC Voltage |
600 mV / 6 V / 60 V / 600 V; ±(0.7% + 3 digits) |
| DC Current |
600 µA / 60 mA / 600 mA / 6 A / 10 A; ±(1.0% + 3 digits) |
| AC Current |
600 µA / 60 mA / 600 mA / 6 A / 10 A; ±(1.2% + 3 digits) |
| Resistance |
600 Ω / 6 kΩ / 60 kΩ / 600 kΩ / 6 MΩ / 60 MΩ; ±(0.8% + 2 digits) |
| Capacitance |
Up to 9.999 mF; ±(4.0% + 5 digits) |
| Frequency |
10 Hz – 1 MHz; ±(0.1% + 5 digits) |
| Temperature |
–40°C to 1000°C / –40°F to 1832°F; ±(1% to 1.5% + 4 to 5 digits) |
| Continuity Test |
Yes (audible beep if <10 Ω) |
| Diode Test |
Yes |
| NCV (Non-Contact Voltage) |
Yes |
| Additional Features |
Data hold, low battery indicator, overload protection, auto power off, 2 m drop-proof |
| Safety Rating |
CAT III 600 V, double insulation |
| Power Supply |
2 × 1.5 V AAA batteries |
| Dimensions |
155 × 76.5 × 49 mm |
| Weight |
255 g (with batteries) |
| Accessories |
Test leads, user manual, K-type thermocouple |
